SPMG Drills Set's 5xD

ab €162.00

Availability: 2147483647 In Stock

Set Indexable Drill for Inserts SPMG

consisting of:
1x SDUM ... SPMG Indexable Drill 5xD

10x Drill Inserts SPMG... -PM RT330 (Steel and Stainless Steel)

Packaging unit = 1 Pc.

Drill of Choice:

	DrillingØ	ClampingØ	Drilling Depth	SPMG
SDUM 13XD5	13	20	65	050204
SDUM 14XD5	14	20	70	050204
SDUM 15XD5	15	20	75	050204
SDUM 16XD5	16	25	80	060204
SDUM 17XD5	17	25	85	060204
SDUM 18XD5	18	25	90	060204
SDUM 19XD5	19	25	95	060204
SDUM 20XD5	20	25	100	060204

Rinaldi-Tools

SPMG Drills Set's 4xD

ab €161.00

Availability: 2147483647 In Stock

Set Indexable Drill for Inserts SPMG

consisting of:
1x SDUM ... SPMG Indexable Drill 4xD

10x Drill Inserts SPMG... -PM RT330 (Steel and Stainless Steel)

Packaging unit = 1 Pc.

Drill of Choice:

DrillØ	SpannØ	Drill Depth	SPMG
12,5	20	52	050204
13	20	52	050204
13,5	20	52	050204
14	20	56	050204
14,5	20	56	050204
15	20	60	050204
15,5	20	60	060204
16	25	64	060204
16,5	25	66	060204
17	25	68	060204
17,5	25	70	060204
18	25	72	060204
18,5	25	74	060204
19	25	76	060204
19,5	25	78	060204
20	25	80	060204
20,5	25	82	060204
21	25	84	060204
21,5	25	86	060204
22	25	88	07T308
22,5	25	90	07T308
23	25	92	07T308
23,5	25	94	07T308
24	25	96	07T308
24,5	25	98	07T308
25	25	100	07T308
25,5	25	102	07T308
26	25	104	07T308
26,5	25	106	07T308
27	25	108	07T308
27,5	25	110	07T308
28	25	112	090408
28,5	25	114	090408
29	25	116	090408
29,5	25	118	090408
30	32	120	090408
31	32	124	090408
32	32	128	090408
33	32	132	090408
34	32	136	110408
35	32	140	110408
36	32	144	110408
37	32	148	110408
38	32	152	110408
39	32	156	110408
40	32	160	110408

Rinaldi-Tools

SPMG Drills Set's 3xD

ab €132.00

Availability: 2147483646 In Stock

Set Indexable Drill for Inserts SPMG

consisting of:
1x SDUM ... SPMG Indexable Drill 3xD

10x Drill Inserts SPMG... -PM RT330 (Steel and Stainless Steel)

Packaging unit = 1 Pc.

Drill of Choice:

DrillØ	SpannØ	Drill Depth 3xD	SPMG
12,5	20	37	050204
13	20	39	050204
13,5	20	40,5	050204
14	20	42	050204
14,5	20	43,5	050204
15	20	45	050204
15,5	20	46,5	060204
16	25	48	060204
16,5	25	49,5	060204
17	25	51	060204
17,5	25	52,5	060204
18	25	54	060204
18,5	25	55,5	060204
19	25	57	060204
19,5	25	58,5	060204
20	25	60	060204
20,5	25	61,5	060204
21	25	63	060204
21,5	25	64,5	060204
22	25	66	07T308
22,5	25	67,5	07T308
23	25	69	07T308
23,5	25	70,5	07T308
24	25	72	07T308
24,5	25	73,5	07T308
25	25	75	07T308
25,5	25	76,5	07T308
26	25	78	07T308
26,5	25	79,5	07T308
27	25	81	07T308
27,5	25	82,5	07T308
28	25	84	090408
28,5	25	85,5	090408
29	25	87	090408
29,5	25	88,5	090408
30	32	90	090408
31	32	93	090408
32	32	96	090408
33	32	99	090408
34	32	102	110408
35	32	105	110408
36	32	108	110408
37	32	111	110408
38	32	114	110408
39	32	117	110408
40	32	120	110408
41	32	123	110408

Rinaldi-Tools

SPMG Drills Set's 2xD

ab €125.00

Availability: 2147483647 In Stock

Set Indexable Drill for Inserts SPMG

consisting of:
1x SDUM ... SPMG Indexable Drill 2xD

10x Drill Inserts SPMG... -PM RT330 (Steel and Stainless Steel)

Packaging unit = 1 Pc.

Drill of Choice:

	DrillØ	ClampingØ	Drill Depth	SPMG
12.5XD2	12,5	20	25	050204
13XD2	13	20	26	050204
13.5XD2	13,5	20	27	050204
14XD2	14	20	28	050204
14.5XD2	14,5	20	29	050204
15XD2	15	20	30	050204
15.5XD2	15,5	20	31	060204
16XD2	16	25	32	060204
16.5XD2	16,5	25	33	060204
17XD2	17	25	34	060204
17.5XD2	17,5	25	35	060204
18XD2	18	25	36	060204
18.5XD2	18,5	25	37	060204
19XD2	19	25	38	060204
19.5XD2	19,5	25	39	060204
20XD2	20	25	40	060204
20.5XD2	20,5	25	41	060204
21XD2	21	25	42	060204
21.5XD2	21,5	25	43	060204
22XD2	22	25	44	07T308
22.5XD2	22,5	25	45	07T308
23XD2	23	25	46	07T308
23.5XD2	23,5	25	47	07T308
24XD2	24	25	48	07T308
24.5XD2	24,5	25	49	07T308
25XD2	25	25	50	07T308
25.5XD2	25,5	25	51	07T308
26XD2	26	25	52	07T308
26.5XD2	26,5	25	53	07T308
27XD2	27	25	54	07T308
27.5XD2	27,5	25	55	07T308
28XD2	28	25	56	090408
28.5XD2	28,5	25	57	090408
29XD2	29	25	58	090408
29.5XD2	29,5	25	59	090408
30XD2	30	32	60	090408
31XD2	31	32	62	090408
32XD2	32	32	64	090408
33XD2	33	32	66	090408
34XD2	34	32	68	110408
35XD2	35	32	70	110408
36XD2	36	32	72	110408
37XD2	37	32	74	110408
38XD2	38	32	76	110408
39XD2	39	32	78	110408
40XD2	40	32	80	110408
41XD2	41	32	82	110408
42XD2	42	32	84	140512
43XD2	43	32	86	140512
44XD2	44	32	88	140512
45XD2	45	40	90	140512
46XD2	46	40	92	140512
47XD2	47	40	94	140512
48XD2	48	40	96	140512
49XD2	49	40	98	140512
50XD2	50	40	100	140512

NEW

OUR FREE CATALOGS

Rinaldi-Tools Tool Overview 2024

ab €0.00

Availability: 2147483617 In Stock

Free print-version of our current "Best of" product catalog for 2024.

Rinaldi-Tools Mold and Tool Making 2024

ab €0.00

Availability: 2147483631 In Stock

Free print-version of our current "Mold and Tool Making" product catalog for 2024.

Rinaldi-Tools Prisma-Line

ab €0.00

Availability: 2147483645 In Stock

Free print-version of our current "Prisma-Line" booklet.

Mill Type	Solid Carbide End Mill for Aluminum
Helix Angle	35°
Workpiece Material	NF-Materials
Lenght	Standard Lenght
Shank	Cylindrical Shank
Flutes	3
Grade	RT30K: Uncoated K30 carbide substrate for machining non-ferrous metals
Packaging unit	1 Pc

Mill Type	Solid Carbide End Mill for Aluminum
Helix Angle	35°
Workpiece Material	Non-Ferrous Metals
Lenght	Standard Lenght
Shank	Cylindrical Shank
Flutes	3
Grade	RT107: The DLC coating (Diamond-Like Carbon) ensures higher wear resistance.
Packaging unit	1 Pc

Mill Type	Solid Carbide End Mill
Helix Angle	38°
Workpiece Material	Steel, Stainless Steel, Cast Iron
Processing	Finish
Lenght	Standard Length
Shank	Weldon-Shank
Flutes	4
Grade	RT405: PVD-TIALN-coated high-performance grade for solid carbide milling cutters
Packaging unit	1 Pc

Mill Type	Solid Carbide Hard Milling Cutter
Helix Angle	45°
Workpiece Material	Hard Materials up to 68 HRC
Lenght	Standard Length
Shank	Cylindrical Shank
Flutes	4
Grade	RT555: PVD-coated carbide substrate for the Hard machining of steel (up to HRC 55-68). Highest wear resistance and toughness
Packaging unit	1 Pc.

Insert size	16
Inside/Outside Thread	Outside
Direction	Right
Thread Type	Metric
Profile	Full profile
Workpiece Materials	Steel, Stainless Steel, Special Materials, NF-Metals
Flank angle	60°
Grade	RT315 = PVD-coated P15-P25 and M10-M25 for universal use
Packaging Unit	5 x 2 pc.

	D	d	H	L	Z	Version
5 x AF-P-Z3-D3.0 RT30K	3	6	9	50	3	A
5 x AF-P-Z3-D4.0 RT30K	4	6	10	60	3	A
5 x AF-P-Z3-D5.0 RT30K	5	6	13	50	3	A
5 x AF-P-Z3-D6.0 RT30K	6	6	16	60	3	B
5 x AF-P-Z3-D8.0 RT30K	8	8	20	60	3	B
5 x AF-P-Z3-D10.0 RT30K	10	10	25	75	3	B
5 x AF-P-Z3-D12.0 RT30K	12	12	30	75	3	B

	D	d	H	L	Z	Version
5 x AF-P-Z3-D4.0 RT107	4	6	10	50	3	A
5 x AF-P-Z3-D5.0 RT107	5	6	15	50	3	A
5 x AF-P-Z3-D6.0 RT107	6	6	18	60	3	B
5 x AF-P-Z3-D8.0 RT107	8	8	20	60	3	B
5 x AF-P-Z3-D10.0 RT107	10	10	25	75	3	B

	D	d(h6)	H	L	Z	Version
SF-P-Z4-D3.0-W RT405	3	6	8	50	4	A
SF-P-Z4-D4.0-W RT405	4	6	11	50	4	A
SF-P-Z4-D5.0-W RT405	5	6	13	50	4	A
SF-P-Z4-D6.0-W RT405	6	6	16	50	4	B
SF-P-Z4-D8.0-W RT405	8	8	20	60	4	B
SF-P-Z4-D10.0-W RT405	10	10	25	75	4	B
SF-P-Z4-D12.0-W RT405	12	12	30	75	4	B

	D	d(h6)	H	L	Z	Version
5 x HF-P-Z4-D1.0 RT555	1	6	3	50	4	A
5 x HF-P-Z4-D2.0 RT555	2	6	6	50	4	A
5 x HF-P-Z4-D3.0 RT555	3	6	8	50	4	A
5 x HF-P-Z4-D3.5 RT555	3,5	6	10	50	4	A
5 x HF-P-Z4-D4.0 RT555	4	6	11	50	4	A
5 x HF-P-Z4-D5.0 RT555	5	6	13	50	4	A
5 x HF-P-Z4-D5.5 RT555	5,5	6	16	50	4	A
5 x HF-P-Z4-D6.0 RT555	6	6	16	50	4	B
5 x HF-P-Z4-D8.0 RT555	8	8	20	60	4	B
5 x HF-P-Z4-D10.0 RT555	10	10	25	75	4	B
5 x HF-P-Z4-D12.0 RT555	12	12	30	75	4	B

	h	W	L	S	T(max)
BDKTR 1212-K2C für MGMN 200 (2mm)	12	12	100	12,3	15
BDKTL 1212-K2C für MGMN 200 (2mm)	12	12	100	12,3	15
BDKTR 1616-K2C für MGMN 200 (2mm)	16	16	125	16,3	18
BDKTL 1616-K2C für MGMN 200 (2mm)	16	16	125	16,3	18
BDKTR 2020-K2C für MGMN 200 (2mm)	20	20	125	20,3	18
BDKTL 2020-K2C für MGMN 200 (2mm)	20	20	125	20,3	18
BDKTR 2525-K2C für MGMN 200 (2mm)	25	25	150	25,3	18
BDKTL 2525-K2C für MGMN 200 (2mm)	25	25	150	25,3	18

	h	W	L	S	T(max)
BDKTR 2020-K4C für MGMN 400 (4mm)	20	20	125	20,4	20
BDKTL 2020-K4C für MGMN 400 (4mm)	20	20	125	20,4	20
BDKTR 2525-K4C für MGMN 400 (4mm)	25	25	150	25,4	22
BDKTL 2525-K4C für MGMN 400 (4mm)	25	25	150	25,4	22

	d	D	L	l	h	f	t max	D min
BIKTR/L 16-K2C Stechbreite 2mm	16	20	150	33	15	11,5	4	20
BIKTR/L 20-K2C Stechbreite 2mm	20	16	170	33	18	14,5	6	26

	d	D	L	l	h	f	t max	D min
BIKTR/L 20-K3C 3mm	20	26	170	33	18	15	6	26
BIKTR/L 25-K3C 3mm	25	32	200	45	23	18,5	7	32
BIKTR/L 32-K3C 3mm	32	40	250	49	30	22	8	40

	d	D	L	l	h	f	t max	D min
BIKTR/L 25-K4C 4mm	25	32	200	45	23	18,5	7
BIKTR/L 32-K4C 4mm	32	40	250	49	30	22	8

	h	W	L	S	T(max)
BDKTR 1212-K3C für MGMN 300 (3mm)	12	12	100	12,3	18
BDKTL 1212-K3C für MGMN 300 (3mm)	12	12	100	12,3	18
BDKTR 1616-K3C für MGMN 300 (3mm)	16	16	125	16,4	18
BDKTL 1616-K3C für MGMN 300 (3mm)	16	16	125	16,4	18
BDKTR 2020-K3C für MGMN 300 (3mm)	20	20	125	20,4	20
BDKTL 2020-K3C für MGMN 300 (3mm)	20	20	125	20,4	20
BDKTR 2525-K3C für MGMN 300 (3mm)	25	25	150	25,4	22
BDKTL 2525-K3C für MGMN 300 (3mm)	25	25	150	25,4	22

	ISO	Pitch	I.C	S	d
2 x 16ER-V-ISO-1,0-G RT315	16	1,0 mm	9,525	3,52	4
2 x 16ER-V-ISO-1,25-G RT315	16	1,25 mm	9,525	3,52	4
2 x 16ER-V-ISO-1,5-G RT315	16	1,5 mm	9,525	3,52	4
2 x 16ER-V-ISO-1,75-G RT315	16	1,75 mm	9,525	3,52	4
2 x 16ER-V-ISO-2,0-G RT315	16	2,0 mm	9,525	3,52	4

	ISO	Pitch	I.C	S	d
2 x 16IR-V-ISO-1,0 RT315	16	1,0 mm	9,525	3,52	4
2 x 16IR-V-ISO-1,25 RT315	16	1,25 mm	9,525	3,52	4
2 x 16IR-V-ISO-1,5 RT315	16	1,5 mm	9,525	3,52	4
2 x 16IR-V-ISO-1,75 RT315	16	1,75 mm	9,525	3,52	4
2 x 16IR-V-ISO-2,0 RT315	16	2,0 mm	9,525	3,52	4

	r	L	I.C	S
SPMG 050204-PM-RT330	0,4	5	5	2,38
SPMG 060204-PM-RT330	0,4	6	6	2,38
SPMG 07T308-PM-RT330	0,8	7,94	7,94	3,97
SPMG 090408-PM-RT330	0,8	9,8	9,8	4,30
SPMG 110408-PM-RT330	0,8	11,5	11,5	4,80
SPMG 140512-PM-RT330	1,2	14,3	14,3	5,20

	ISO	Pitch	I.C	S	d
16ER-V-ISO-1,0-G RT315	16	1,0mm	9,525	3,52	4
16ER-V-ISO-1,25-G RT315	16	1,25mm	9,525	3,52	4
16ER-V-ISO-1,5-G RT315	16	1,5mm	9,525	3,52	4
16ER-V-ISO-1,75-G RT315	16	1,75mm	9,525	3,52	4
16ER-V-ISO-2,0-G RT315	16	2,0mm	9,525	3,52	4
16ER-V-ISO-2,5-G RT315	16	2,5mm	9,525	3,52	4
16ER-V-ISO-3,0-G RT315	16	3,0mm	9,525	3,52	4

	h	W	L	S	T(max)
BDKTR 2020-K5C für MGMN 500 (5mm)	20	20	125	20,4	20
BDKTL 2020-K5C für MGMN 500 (5mm)	20	20	125	20,4	20
BDKTR 2525-K5C für MGMN 500 (5mm)	25	25	150	25,4	25
BDKTL 2525-K5C für MGMN 500 (5mm)	25	25	150	25,4	25
BDKTL 3232-K5C für MGMN 500 (5mm)	32	32	170	32,5	25
BDKTL 3232-K5C für MGMN 500 (5mm)	32	32	170	32,5	25

Insert size	16
Inside/Outside Thread	Inside
Direction	Right
Thread Type	Metric
Profile	Full profile
Workpiece Materials	Steel, Stainless Steel, Special Materials, NF-Metals
Flank angle	60°
Grade	RT315 = PVD-coated P15-P25 and M10-M25 for universal use
Packaging Unit	2 pc.

Shape	SPMG
Material	Steel and Stainless Steel
Grade	RT330: PVD-coated P15-P25 and M10-M25 for universal use in steel, and stainless steel
Packaging unit	10 Pc

Tool	Solid Carbide short step drill
Material	Steel, Stainless Steel, Cast Iron
Usable Lenght	3xD
Shank	Cylindrical Shank
Packaging unit	1 Pc

	D(m8)	d(h6)	D2(m7)	L	L2	L3	L1
VSB-M4-3xD-Z	3,3	6	4,5	66	28	36	11,4
VSB-M5-3xD-Z	4,2	6	6	66	28	36	13,6
VSB-M6-3xD-Z	5	8	7	79	41	36	16,5
VSB-M8-3xD-Z	6,75	10	9,5	89	47	40	21
VSB-M8x1,0-3xD-Z	7	10	9,8	89	47	40	21
VSB-M10-3xD-Z	8,5	12	12	102	55	45	25,5
VSB-M10x1,0-3xD-Z	9	12	12	102	55	45	25,5
VSB-M12-3xD-Z	10,25	14	14	107	60	45	30
VSB-M14-3xD-Z	12	16	16	115	65	48	34,5
VSB-M16-3xD-Z	14	18	18	123	73	48	38,5

Grooving Holder	BDKTR/L t max:40
Application	Outside Grooving
Grooving System	MGM./MRM.-System
Grooving Insert	MGMN/MGMR/MRMN...
Packaging Unit	1 Pc.

	h=H	B	L	f	t max	d max
BDKTR 2525-K3C t max:40 for MG../MR 300 (3mm)	25	25	170	25,4	40	84
BDKTL 2525-K3C t max:40 for MG../MR 300 (3mm)	25	25	170	25,4	40	84
BDKTR 2525-K4C t max:40 for MG../MR 400 (4mm)	25	25	170	25,4	40	84
BDKTL 2525-K4C t max:40 for MG../MR 400 (4mm)	25	25	170	25,4	40	84

External Tool Holder	SRHCR/L
Insert	RC.
Main application	Longitudinal turning
Clamping	Screw Clamp
Packaging unit	1 Pc.

	h=H	B	L	f	Insert
SRHCR 2020 K10	20	20	120	20	RCG./RCM. 10..
SRHCL 2020 K10	20	20	120	20	RCG./RCM. 10..
SRHCR 2525 K10	25	25	120	25	RCG./RCM. 10..
SRHCL 2525 K10	25	25	120	25	RCG./RCM. 10..
SRHCR 2020 K12	20	20	120	20	RCG./RCM. 12..
SRHCL 2020 K12	20	20	120	20	RCG./RCM. 12..
SRHCR 2525 K12	25	25	120	25	RCG./RCM. 12..
SRHCL 2525 K12	25	25	120	25	RCG./RCM. 12..

Shape	CNMG
Processing	Finish
Workpiece Material	Steel and Stainless Steel
Grade	RTC+: PVD coated P05-P15 Cermet grade for finishing of steel and stainless steel
Packaging unit	10 Pc.

TURNING

MILLING

DRILLING

SPMG DRILL SETS- ONLY FOR A SHORT TIME!

Set Indexable Drill for Inserts SPMG

consisting of:1x SDUM ... SPMG Indexable Drill 5xD

10x Drill Inserts SPMG... -PM RT330 (Steel and Stainless Steel)

Drill of Choice:

Set Indexable Drill for Inserts SPMG

consisting of:1x SDUM ... SPMG Indexable Drill 4xD

10x Drill Inserts SPMG... -PM RT330 (Steel and Stainless Steel)

Drill of Choice:

Set Indexable Drill for Inserts SPMG

consisting of:1x SDUM ... SPMG Indexable Drill 3xD

10x Drill Inserts SPMG... -PM RT330 (Steel and Stainless Steel)

Drill of Choice:

Set Indexable Drill for Inserts SPMG

consisting of:1x SDUM ... SPMG Indexable Drill 2xD

10x Drill Inserts SPMG... -PM RT330 (Steel and Stainless Steel)

Drill of Choice:

SPECIAL OFFER

BDKTR/L + 10x MGMN 2 mm

Inserts of your Choice:

NEW

OUR FREE CATALOGS

Free print-version of our current "Best of" product catalog for 2024.

Free print-version of our current "Mold and Tool Making" product catalog for 2024.

Free print-version of our current "Prisma-Line" booklet.

100% SECURE PAYMENT

PAYPAL PAYMENT

ADVISORY

FAST DELIVERY WITH UPS

consisting of:
1x SDUM ... SPMG Indexable Drill 5xD

consisting of:
1x SDUM ... SPMG Indexable Drill 4xD

consisting of:
1x SDUM ... SPMG Indexable Drill 3xD

consisting of:
1x SDUM ... SPMG Indexable Drill 2xD

	r	L	I.C.	S
CNMG 090304-SF RTC+	0,4	9,7	9,525	3,18
CNMG 120404-SF RTC+	0,4	12,9	12,7	4,76
CNMG 120408-SF RTC+	0,8	12,9	12,7	4,76

Shape	DNMG
Processing	Finish
Workpiece Material	Steel and Stainless Steel
Grade	RTC+: PVD coated P05-P15 Cermet grade for finishing of steel and stainless steel
Packaging unit	10 Pc.

	r	L	I.C	S	d
DNMG 110404-SF RTC+	0,4	11,6	9,525	4,76	3,81
DNMG 150604-SF RTC+	0,4	15,5	12,7	6,35	5,16
DNMG 150608-SF RTC+	0,8	15,5	12,7	6,35	5,16

Shape	CCGT
Processing	Finish
Worpiece Material	Steel and Stainless Steel
Grade	RTC+:PVD coated P05-P15 Cermet grade for finishing of steel and stainless steel
Packaging unit	10 Pc.

	r	L	I.C	S	d
CCGT 060202-SF RTC+	0,2	6,4	6,35	2,38	2,8
CCGT 060204-SF RTC+	0,4	6,4	6,35	2,38	2,8
CCGT 09T302-SF RTC+	0,2	9,7	9,525	3,97	4,4
CCGT 09T304-SF RTC+	0,4	9,7	9,525	3,97	4,4

Shape	DCGT
Processing	Finish
Workpiece Material	Steel and Stainless Steel
Grade	RTC+:PVD coated P05-P15 Cermet grade for finishing of steel and stainless steel
Packaging unit	10 Pc.

	r	L	I.C	S	d
DCGT 070202-SF RTC+	0,2	7,8	6,35	2,38	2,8
DCGT 070204-SF RTC+	0,4	7,8	6,35	2,38	2,8
DCGT 070208-SF RTC+	0,8	7,8	6,35	2,38	2,8
DCGT 11T302-SF RTC+	0,2	11,6	9,525	3,97	4,4
DCGT 11T304-SF RTC+	0,4	11,6	9,525	3,97	4,4
DCGT 11T308-SF RTC+	0,8	11,6	9,525	3,97	4,4

External Tool Holder	DVVNN
Cutting Angle	72,5°
Insert	VN..
Main application	Longitudinal turning
Clamping	Pin Lock
Packaging unit	1 Pc.

	h=H	B	L	L1	f	Wendeplatte
DVVNN 2020 K16	20	20	125	45	10	VN.. 1604..
DVVNN 2525 M16	25	25	150	45	12,5	VN.. 1604..

External Tool Holder	DVJNR/L
Cutting Angle	93°
Insert	VN..
Main application	Longitudinal turning
Clamping	Pin Lock
Packaging unit	1 Pc.
