Internal Tool Holders

Rinaldi Tools offers a large selection of internal turning tool holders for all applications. Our holders are made from high-quality steel to ensure maximum durability and reliability, even under high stress. We recommend using them with our turning inserts to achieve the best possible results.

Solid Carbide Internal Tool Holder E-SDQCR/L | Rinaldi-Tools
  • -€16.00
Rinaldi-Tools GmbH

Solid Carbide Internal Tool Holder - E-SDQCR/L (107,5°) with cooling holes

Regular price €156.00 Price ab €140.00 -€16.00
Availability: 9999 In Stock

Technical data

Boring Bar E-SDQCR/L
Setting Angle 107,5°
Insert DC..
Main application Profile turning
Clamping Screw Clamp
Cooling With Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d L f D/min
E10M SDQCR/L-07 10 150 8 ≥13
E12Q SDQCR/L-07 12 180 9 ≥15
E16R SDQCR/L-11 16 200 12 ≥20
E20R SDQCR/L-11 20 250 15 ≥25

Solid carbide internal tool holder E-SDQCR/L for low-vibration profile turning

The solid carbide internal tool holder E-SDQCR/L with a 107.5° approach angle is designed for precise profile turning of internal contours. Equipped with internal cooling holes and a reliable screw clamp for DC... inserts, this tool supports efficient chip evacuation and stable machining processes.

Advantages of the solid carbide internal tool holder E-SDQCR/L

  • Solid carbide boring bar considerably increases tool stability
  • Allows a projection length of up to 6xD by reducing vibrations
  • Improves precision and surface quality on the workpiece
  • Cooling holes support direct coolant supply to the cutting edge
Solid Carbide Internal Tool Holder E-SCLCR/L | Rinaldi-Tools
  • -€11.00
SMOXH

Solid Carbide Internal Tool Holder - E-SCLCR/L (95°) with cooling holes

Regular price €109.00 Price ab €98.00 -€11.00
Availability: 10000 In Stock

Technical data

Boring Bar E-SCLCR/L
Setting Angle 95°
Insert CC..
Main application Longitudinal turning, facing
Clamping Screw Clamp
Cooling With Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d L f Dmin
E08K SCLCR/L 06 8 125 5 ≥10
E10K SCLCR/L 06 10 125 6 ≥12
E12M SCLCR/L 06 12 150 7 ≥14
E16Q SCLCR/L 09 16 180 9 ≥18
E20S SCLCR/L 09 20 250 12,5 ≥25

Solid Carbide Boring Bar for Low-Vibration Machining

The Solid Carbide Internal Tool Holder E-SCLCR/L (95°) with cooling holes is designed for high-precision internal turning and facing. The solid carbide construction significantly reduces vibrations, enabling reliable operations even with long projection lengths.

Advantages of Solid Carbide Internal Tool Holder - E-SCLCR/L (95°) with cooling holes

  • Substantially reduced vibrations allow for projection lengths up to 6xD.
  • Increased precision and superior surface quality thanks to the rigid solid carbide body.
  • Integrated cooling holes provide efficient chip evacuation and thermal control.
  • Reliable screw clamping system for secure holding of CC... inserts.
Solid Carbide Internal Tool Holder E-SDUCR/L | Rinaldi-Tools
  • -€11.00
Rinaldi-Tools GmbH

Solid Carbide Internal Tool Holder - E-SDUCR/L (93°)

Regular price €109.00 Price ab €98.00 -€11.00
Availability: 10000 In Stock

Technical data

Boring Bar E-SDUCR/L
Setting Angle 93°
Insert DC..
Main application Profile turning
Clamping Screw Clamp
Cooling With internal coolant feed
Packaging unit 1 Pc.

Dimensions

  d L f Dmin
E08K SDUCR/L-07 8 125 7 ≥12
E10M SDUCR/L-07 10 150 8 ≥14
E12Q SDUCR/L-07 12 180 9 ≥16
E16R SDUCR/L-11 16 200 12 ≥21
E20S SDUCR/L-11 20 250 14 ≥25

Solid Carbide Internal Tool Holder E-SDUCR/L (93°) for Profile Turning

The Solid Carbide Internal Tool Holder E-SDUCR/L (93°) is engineered for demanding internal turning and profiling applications on CNC lathes. Designed as a solid carbide boring bar, this tool holder significantly minimizes vibrations, which directly improves precision and surface quality. Equipped with an internal coolant feed and a secure screw clamping mechanism for DC... inserts, it ensures optimal chip evacuation and consistent performance in professional machining.

Advantages of Solid Carbide Internal Tool Holder E-SDUCR/L (93°)

  • Solid carbide construction provides superior stability and dampens vibrations.
  • Facilitates deep internal turning with a projection length of up to 6xD.
  • Through-coolant design aids in efficient chip removal and extends insert life.
  • Secure screw clamp ensures precise and stable seating of DC... indexable inserts.
  • 93° setting angle makes it an ideal choice for complex profile turning operations.
Internal Tool Holder SCLCR/L (95°) Boring Bar | Rinaldi-Tools
SMOXH

Internal Tool Holder - SCLCR/L (95°)

Price ab €25.00
Availability: 214748352 In Stock

Technical data

Boring Bar SCLCR/L
Cutting Angle 95°
Insert CC..
Main application Longitudinal turning, Facing
Clamping Screw Clamping
Cooling Without Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d h L L1 f Dmin
S0608H SCLCR/L 06 8* 7 100 25 05 ≥8
S08H SCLCR/L 06 8 7 100 - 07 ≥11
S10K SCLCR/L 06 10 9 125 - 08 ≥13
S12K SCLCR/L 06 12 11 125 - 10 ≥16
S12K SCLCR/L 09 12 11 125 - 10 ≥16
S16P SCLCR/L 09 16 15 170 - 13 ≥21
S20R SCLCR/L 09 20 18 200 - 15 ≥25
S25S SCLCR/L 09 25 23 250 - 19,5 ≥32
S32T SCLCR/L 09 32 30 300 - 24 ≥40

SMOXH SCLCR/L Internal Tool Holder

The SCLCR/L boring bar with a 95° cutting angle is engineered for high precision in internal longitudinal turning and facing. Equipped with a reliable screw clamping system, this holder ensures maximum stability when using CC.. indexable inserts. Note for variant S0608H: *Neck Diameter 6 mm.

Advantages of the SCLCR/L internal tool holder

  • 95° approach angle supports flexible boring and facing tasks
  • Secure insert seating thanks to the robust screw clamping mechanism
  • Fully compatible with standardized CC.. indexable inserts
  • Solid construction minimizes vibrations during machining
Stepped SCLCR/L 95° Internal Tool Holder | Rinaldi-Tools
SMOXH

Internal Tool Holder with stepped shank - SCLCR/L (95°)

Price ab €37.00
Availability: 2147483619 In Stock

Technical data

Boring Bar SCLCR/L with stepped shank
Cutting Angle 95°
Insert CC..
Main application Longitudinal turning, Facing
Clamping Screw Clamping
Cooling Without Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d h L L1 f Dmin
S16x10M SCLCR/L 06 16 15 150 35 8 ≥13
S16x12M SCLCR/L 06 16 15 150 35 10 ≥13

Precise internal machining with the SMOXH SCLCR/L 95°

The internal tool holder SCLCR/L with a stepped shank and a 95° approach angle offers professional users a stable and reliable tool holder for longitudinal and face turning. Equipped with a robust screw clamping system for CC inserts, it ensures accurate cutting performance during internal operations.

Advantages of Internal Tool Holder with stepped shank - SCLCR/L (95°)

  • Secure screw clamping for a firm grip on the indexable insert
  • 95° approach angle enables flexible applications in internal boring and facing
  • Stepped shank design offers clearance benefits in tight machining spaces
  • Designed for professional use with compatible CC.. indexable inserts
SCLCR/L 95° Internal Holder with Cooling - Rinaldi-Tools
SMOXH

Internal Tool Holder - SCLCR/L (95°) with cooling holes

Price ab €32.00
Availability: 2147483593 In Stock

Boring Bar SCLCR/L
Cutting Angle 95°
Insert CC..
Main application Longitudinal turning, Facing
Clamping Screw Clamping
Cooling With Cooling Holes
Packaging unit 1 Pc.

  d h L f Dmin
A08H SCLCR/L 06 with cooling holes 8 7 100 07 ≥11
A10H SCLCR/L 06 with cooling holes 10 9 100 08 ≥13
A12H SCLCR/L 06 with cooling holes 12 11 100 10 ≥16
A16M SCLCR/L 09 with cooling holes 16 15 150 13 ≥21
A20P SCLCR/L 09 with cooling holes 20 19 170 15 ≥25
A25R SCLCR/L 09 with cooling holes 25 23 200 19,5 ≥32

Solid Carbide Internal Tool Holder E-SCLCR/L-03 | Rinaldi-Tools
Rinaldi-Tools GmbH

Solid Carbide Internal Tool Holder - E...-SCLCR/L-03

Price ab €101.00
Availability: 2147483633 In Stock

Technical data

Boring Bar E... SCLCR/L
Cutting Angle 95°
Insert CCGT 03...
Clamping Screw Clamp
Cooling With Cooling Holes
Packaging unit 1 Pc.

Dimensions

Ød L S Dmin
E04J-SCLCR-03 (CCGT 030102L) 4 90 2,5 5
E04J-SCLCL-03 (CCGT 030102R) 4 90 2,5 5
E05J-SCLCR-03 (CCGT 030102L) 5 100 3 6
E05J-SCLCL-03 (CCGT 030102R) 5 100 3 6
E06J-SCLCL-03 (CCGT 030202R) 6 110 3,5 7
E06J-SCLCL-03 (CCGT 030202R) 6 110 3,5 7

High-quality internal tool holder for professional machining

The solid carbide internal tool holder of the E...-SCLCR/L-03 series provides a low-vibration foundation for precise turning operations in bores and difficult-to-reach contours.

Advantages of Solid Carbide Internal Tool Holder - E...-SCLCR/L-03

  • Solid carbide design reduces process-related vibrations
  • Integrated cooling holes support efficient heat dissipation
  • Optimized for CCGT 03 indexable inserts for fine machining
  • Proven screw clamping ensures secure seating of the insert
Internal Tool Holder PCLNR/L 95° for Turning | Rinaldi-Tools
Rinaldi-Tools GmbH

Internal Tool Holder - PCLNR/L (95°)

Price ab €62.00
Availability: 214748354 In Stock

Technical data

Boring Bar SPCLNR/L
Cutting Angle 95°
Insert CN..
Main application Longitudinal turning, Facing
Clamping Pin Lock
Cooling Without Cooling Holes
Packaging unit 1 Pc.

Dimensions

d L h f Dmin
S25Q-PCLNR/L 12 25 180 23 17 32
S25T-PCLNR/L 12
 25 300 23 17 32
S32R-PCLNR/L 12
 32 200 30 22 44
S32U-PCLNR/L 12
 32 350 30 22 44
S40S-PCLNR/L 12
 40 250 37 27 54
S40V-PCLNR/L 12
 40 400 37 27 54
S50S-PCLNR/L 12
 50 250 47 35 63
S50W-PCLNR/L 12
 50 450 47 35 63
S50S-PCLNR/L 19
 50 250 47 35 63
S50W-PCLNR/L 19
 50 450 47 35 63

Internal Tool Holder PCLNR/L (95°) for Professional Machining

The PCLNR/L internal tool holder featuring a 95° cutting angle and reliable pin lock clamping is designed for precision internal boring and facing operations. Compatible with CN inserts, this boring bar provides a well-thought-out solution for dry machining applications without internal cooling. The robust design supports stable insert retention, ensuring consistent performance in demanding environments. Supplied in a practical packaging unit of 1 pc.

Advantages of Internal Tool Holder - PCLNR/L (95°)

  • Designed for efficient internal boring and facing tasks
  • Secure insert positioning achieved by reliable pin lock clamping
  • Compatible with standard CN inserts for flexible application
  • 95° cutting angle creates good conditions for smooth turning operations
PCLNR/L (95°) Internal Tool Holder with Cooling | Rinaldi-Tools
Rinaldi-Tools GmbH

Internal Tool Holder - PCLNR/L (95°) with cooling holes

Price ab €71.00
Availability: 214748348 In Stock

Technical data

Boring Bar PCLNR/L
Cutting Angle 95°
Insert CN..
Main application Longitudinal turning, Facing
Clamping Pin Lock
Cooling With Cooling Hole
Packaging unit 1 Pc.

Dimensions

d L h f Dmin
A25R-PCLNR/L 12 25 200 24 17 32
A32S-PCLNR/L 12 32 250 31 22 44
A32U-PCLNR/L 12 32 350 31 22 44
A40V-PCLNR/L 12 40 400 37 27 54
A50W-PCLNR/L 12 50 450 47 35 63

PCLNR/L – Designed for precise internal turning

The PCLNR/L internal boring bar with a 95° cutting angle and internal cooling holes is tailored for efficient longitudinal turning and facing. It offers high process reliability for professional machining with CN inserts.

Advantages of the PCLNR/L Internal Tool Holder

  • Internal cooling holes support continuous chip evacuation.
  • Pin lock clamping securely fastens the indexable insert.
  • 95° cutting angle is highly suitable for versatile internal operations.
  • Perfectly matched with standardized CN indexable inserts.
TCLNR/L 95° Internal Tool Holder with Clamping | Rinaldi-Tools
SMOXH

Internal Tool Holder - TCLNR/L (95°) with clamping

Price ab €57.00
Availability: 214748363 In Stock

Technical data

Boring Bar TCLNR/L
Cutting Angle 95°
Insert CN..
Main application Longitudinal turning, Facing
Clamping Claw Clamping
Cooling Without Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d h L f Dmin
S20R TCLNR/L-12 20 18 200 15 ≥26
S25S TCLNR/L-12 25 23 250 19,5 ≥38
S32T TCLNR/L-12 32 30 300 24 ≥40
S40U TCLNR/L-12 40 37 350 30 ≥50
S50V TCLNR/L-12 50 47 400 38 ≥63
S40U TCLNR/L-16 40 37 350 30 ≥44

TCLNR/L (95°) Internal Tool Holder for professional machining

The TCLNR/L (95°) internal tool holder with solid claw clamping is specifically designed for the demands of roughing operations. Its stable construction makes it an excellent choice for longitudinal turning and facing. The robust design without cooling channels and the secure insert fixation support efficient workflows even under high cutting forces.

Advantages of the TCLNR/L Internal Tool Holders

  • Particularly suitable for demanding roughing applications
  • Stable claw clamping provides a secure grip on the indexable inserts
  • Creates excellent conditions for precise longitudinal turning and facing
  • Supports reliable machining processes in metalworking
Internal Tool Holder SDUCR/L 93° for DC Inserts | Rinaldi-Tools
SMOXH

Internal Tool Holder - SDUCR/L (93°)

Price ab €28.00
Availability: 214748361 In Stock

Technical data

Boring Bar SDUCR/L
Cutting Angle 93°
Insert DC..
Main application Profiling
Clamping Screw Clamping
Cooling Without Cooling Holes
Packaging unit 1 Pc.

Dimensions

d h L f L1 Dmin
S10K SDUCR/L 07 10 9 125 8 - ≥13
S12K SDUCR/L 07 12 11 125 10 - ≥16
S16P SDUCR/L 07 16 15 170 13 - ≥21
S20R SDUCR/L 07 20 18 200 15 - ≥25
S16P SDUCR/L 11 16 15 170 13 - ≥21
S20R SDUCR/L 11 20 18 200 15 - ≥25
S25S SDUCR/L 11 25 23 250 19,5 - ≥32
S32T SDUCR/L 11 32 30 300 24 - ≥40

Precise internal tool holder for professional machining

The Internal Tool Holder - SDUCR/L (93°) is designed for precise internal turning and efficient profiling. With its rigid construction and compatibility with DC indexable inserts, this tool is an excellent choice for demanding profile turning tasks without internal coolant.

Advantages of Internal Tool Holder - SDUCR/L (93°)

  • Secure screw clamping for reliable retention of DC inserts
  • Versatile application for profile turning and internal machining
  • 93° cutting angle supports good accessibility for complex contours
  • Rigid tool body for stable cutting processes in series production
Stepped Internal Tool Holder SDUCR/L 93° | Rinaldi-Tools
SMOXH

Internal Tool Holder with stepped shank - SDUCR/L (93°)

Price ab €37.00
Availability: 214748359 In Stock

Technical data

Boring Bar SDUCR/L with stepped shank
Cutting Angle 93°
Insert DC..
Main application Profiling
Clamping Screw Clamping
Cooling Without Cooling Holes
Packaging unit 1 Pc.

Dimensions

d h L f L1 Dmin
S16x10M SDUCR/L 07 16 15 150 8 35 ≥13
S16x12M SDUCR/L 07 16 15 150 10 35 ≥16

Reliable stepped internal turning holders SDUCR/L (93°)

The SDUCR/L internal tool holders with a 93-degree approach angle feature a stepped shank designed specifically for demanding profiling and precise internal turning. This stepped design improves access to deeper or narrow bore sections, while the robust screw clamping system ensures a secure fit for the designated DC.. inserts.

Advantages of the stepped internal tool holder SDUCR/L

  • Facilitated access in complex internal contours due to the stepped shank design
  • Stable hold and fast insert indexing thanks to proven screw clamping
  • Practical 93-degree angle tailored for efficient profiling
  • Designed for professional machining applications using standard DC.. indexable inserts
Internal Tool Holder SDUCR/L 93° with Coolant | Rinaldi-Tools
SMOXH

Internal Tool Holder - SDUCR/L (93°) with cooling holes

Price ab €31.00
Availability: 2147483612 In Stock

Technical data

Boring Bar SDUCR/L
Cutting Angle 93°
Insert DC..
Clamping Screw Clamping
Cooling With Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d h L f Dmin Insert
A10H SDUCR/L-07 mit IK 10 09 100 08 ≥13 DCG./DCM. 07..
A12H SDUCR/L-07 mit IK 12 11 100 10 ≥16 DCG./DCM. 07..
A16M SDUCR/L-07 mit IK 16 15 150 13 ≥21 DCG./DCM. 07..
A16M SDUCR/L-11 mit IK 16 15 150 13 ≥21 DCG./DCM. 11..
A20P SDUCR/L-11 mit IK 20 18 170 15 ≥25 DCG./DCM. 11..
A25R SDUCR/L-11 mit IK 25 23 200 19,5 ≥32 DCG./DCM. 11..
A32S SDUCR/L-11 mit IK 32 30 250 24 ≥40 DCG./DCM. 11..

Precise Profile Turning with Effective Cooling

The Internal Tool Holder - SDUCR/L (93°) with cooling holes by SMOXH provides a professional solution for demanding internal turning operations. With its 93° cutting angle, this holder is particularly suitable for profile turning in narrow spaces. The integrated cooling holes ensure that the coolant is directed straight to the cutting edge. This supports efficient chip evacuation and creates excellent conditions for stable turning processes.

Advantages of Internal Tool Holder - SDUCR/L (93°) with cooling holes

  • Targeted chip evacuation and improved cooling efficiency thanks to the integrated cooling holes.
  • Flexible application for demanding profile turning tasks with the 93° approach angle.
  • Reliable clamping of DC indexable inserts through the proven screw clamping system.
  • Convinces with a practical design tailored for professional turning environments.
Internal Tool Holder - SDQCR/L (107,5°) SMOXH | Rinaldi-Tools
SMOXH

Internal Tool Holder - SDQCR/L (107,5°)

Price ab €29.00
Availability: 2147483628 In Stock

Technical data

Boring Bar SDQCR/L
Cutting Angle 107,5°
Insert DC..
Main application Profiling
Clamping Screw Clamping
Cooling Without Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d h L f Dmin Insert
S12K SDQCR/L-07 12 11 125 10 ≥16 DCG./DCM. 07..
S16P SDQCR/L-07 16 15 170 13 ≥21 DCG./DCM. 07..
S16P SDQCR/L-11
 16 15 170 13 ≥21 DCG./DCM. 11..
S20R SDQCR/L-11
 20 18 200 15 ≥25 DCG./DCM. 11..
S25S SDQCR/L-11
 25 23 250 19,5 ≥32 DCG./DCM. 11..

Precision internal tool holder for demanding profile turning

The Internal Tool Holder - SDQCR/L (107,5°) from SMOXH is designed for professional internal turning and complex profiling operations. This robust boring bar utilizes a stable screw clamping system and, with its 107.5-degree approach angle, offers excellent accessibility during contour machining. It is perfectly matched for use with DC indexable inserts and supports efficient machining processes.

Advantages of Internal Tool Holder - SDQCR/L (107,5°)

  • Proven screw clamping creates a reliable and secure insert fixation.
  • The 107.5° approach angle opens up flexible application possibilities in profile turning.
  • Compact design enables effective internal machining from a minimum bore diameter of 16 mm.
  • Designed for field-tested DC indexable inserts, providing high cost-effectiveness.
SDQCR/L 107.5° Boring Bar with Cooling | Rinaldi-Tools
SMOXH

Internal Tool Holder - SDQCR/L (107,5°) with cooling holes

Price ab €32.00
Availability: 2147483621 In Stock

Technical data

Boring Bar SDQCR/L
Cutting Angle 107,5°
Insert DC..
Main application Profiling
Clamping Screw Clamping
Cooling With Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d h L f Dmin Insert
A10H SDQCR/L-07 with cooling holes 10 09 100 08 ≥13 DCG./DCM. 07..
A12H SDQCR/L-07 with cooling holes 12 11 100 10 ≥16 DCG./DCM. 07..
A16M SDQCR/L-07 with cooling holes 16 15 150 13 ≥21 DCG./DCM. 07..
A16M SDQCR/L-11 with cooling holes
 16 15 150 13 ≥21 DCG./DCM. 11..
A20P SDQCR/L-11 with cooling holes
 20 18 170 15 ≥25 DCG./DCM. 11..
A25R SDQCR/L-11 with cooling holes
 25 23 200 19,5 ≥32 DCG./DCM. 11..
A32S SDQCR/L-11 with cooling holes 32 30 250 24 ≥40 DCG./DCM. 11..

Precision Boring Bar for Demanding Profiling

The SMOXH internal tool holder SDQCR/L featuring a 107.5° approach angle and internal cooling is engineered for profiling operations inside bores. Utilizing a secure screw clamping system, this holder accommodates DC inserts reliably and enables accurate contouring on complex workpieces.

Advantages of the SDQCR/L Boring Bars

  • Internal cooling holes support efficient chip evacuation
  • 107.5° approach angle facilitates versatile profile turning
  • Reliable screw clamping provides a secure fit for DC inserts
  • Suitable for precise internal machining in narrow spaces
  • Packaging unit: 1 piece per delivery
SDXCR/L 93° Internal Tool Holder for Back Boring | Rinaldi-Tools
SMOXH

Internal Tool Holder - SDXCR/L (93°)

Price ab €29.00
Availability: 2147483635 In Stock

Technical data

Boring Bar SDXCR/L
Cutting Angle 93°
Insert DC..
Hauptanwendung Back Boring
Clamping Screw Clamping
Cooling Without Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d h L f Dmin Insert
S12K SDXCR-07 12 11 125 11 ≥17 DCM./DCG. 0702..
S12K SDXCL-07 12 11 125 11 ≥17 DCM./DCG. 0702..
S16P SDXCR-11 16 15 170 13 ≥21 DCM./DCG. 11T3..
S16P SDXCL-11 16 15 170 13 ≥21 DCM./DCG. 11T3..
S20R SDXCR-11 20 18 200 15 ≥25 DCM./DCG. 11T3..
S20R SDXCL-11 20 18 200 15 ≥25 DCM./DCG. 11T3..

Specialized Boring Bar for Back Boring

The SMOXH Internal Tool Holder SDXCR/L (93°) is specifically engineered for internal turning in reverse directions. Featuring a 93° cutting angle and a robust structure, this tool enables efficient back boring in challenging workpieces. The holder is perfectly adapted to accommodate standard DC.. indexable inserts.

Advantages of Internal Tool Holder SDXCR/L (93°)

  • Designed specifically for the requirements of reverse machining
  • Reliable screw clamping securely holds DC.. inserts even under varying loads
  • Flexible application in bores starting from a minimum diameter of 17 mm
  • Solid shank construction without internal cooling channels promotes high tool stability
Internal Tool Holder PDUNR/L 93° for Profiling | Rinaldi-Tools
Rinaldi-Tools GmbH

Internal Tool Holder - PDUNR/L (93°)

Price ab €65.50
Availability: 214748364 In Stock

Technical data

Boring Bar PDUNR/L
Cutting Angle 93°
Insert DN..
Main application Profiling
Clamping Pin Lock
Cooling Without Cooling Hole
Packaging unit 1 Pc.

Dimensions

d L h f Dmin
S20Q-PDUNR/L 11 20 180 18 13 25
S20S-PDUNR/L 11
 20 250 18 13 25
S25Q-PDUNR/L 11
 25 180 23 17 32
S25T-PDUNR/L 11
 25 300 23 17 32
S32R-PDUNR/L 11
 32 200 30 22 40
S32U-PDUNR/L 11
 32 350 30 22 40
S32R-PDUNR/L 15
 32 200 30 22 40
S32U-PDUNR/L 15
 32 350 30 22 40
S40S-PDUNR/L 15
 40 250 37 27 50
S40V-PDUNR/L 15
 40 400 37 27 50
S50V-PDUNR/L 15 50 400 47 32 60

Precise Profiling with the Internal Tool Holder PDUNR/L (93°)

The PDUNR/L internal tool holder is designed specifically for professional internal turning and contouring tasks. Featuring a 93-degree approach angle and a proven pin lock clamping system, this boring bar ensures a highly secure hold for DN series inserts.

Advantages of Internal Tool Holder PDUNR/L

  • Reliable pin lock clamping provides stable seating for DN inserts
  • Optimal 93° cutting angle supports accurate profiling operations
  • Solid construction without a cooling hole, ideal for external coolant supply
  • Supplied in a convenient packaging unit of exactly one piece
PDUNR/L 93° Internal Tool Holder with Cooling | Rinaldi-Tools
Rinaldi-Tools GmbH

Internal Tool Holder - PDUNR/L (93°) with cooling holes

Price ab €77.00
Availability: 214748361 In Stock

Technical data

Boring Bar PDUNR/L
Cutting Angle 93°
Insert DN..
Main application Profiling
Clamping Pin Lock
Cooling With Cooling Hole
Packaging unit 1 Pc.

Dimensions

d L h f Dmin
A25R-PDUNR/L 11
 25 200 24 17 32
A32S-PDUNR/L 15
 32 250 31 22 40

Internal Tool Holder - PDUNR/L (93°) with cooling holes

The PDUNR/L internal tool holder with a 93° cutting angle and internal cooling is tailored for professional profile turning tasks. Utilizing DN-type inserts, it delivers process reliability and supports efficient workflows during demanding internal machining operations.

Advantages of Internal Tool Holder - PDUNR/L (93°) with cooling holes

  • Internal cooling hole promotes effective chip evacuation in deep bores
  • Secure pin lock clamping holds the insert firmly in position
  • 93° cutting angle accommodates a variety of internal profiling applications
  • Designed for high stability and reliable performance in professional turning
Internal Tool Holder TDUNR/L 93° with Clamping | Rinaldi-Tools
SMOXH

Internal Tool Holder - TDUNR/L (93°) with clamping

Price ab €59.00
Availability: 214748363 In Stock

Technical data

Boring Bar TDUNR/L
Cutting Angle 93°
Insert DN..
Main application Profiling
Clamping Claw Clamping
Cooling Without Cooling Holes
Packaging unit 1 Pc.

Dimensions

  d h L f Dmin Insert
S25S TDUNR-11 25 23 250 19,5 ≥33 DNM. 1104..
S25S TDUNL-11 25 23 250 19,5 ≥33 DNM. 1104..
S32T TDUNR-11 32 30 300 24 ≥40
 DNM. 1104..
S32T TDUNL-11 32 30 300 24 ≥40 DNM. 1104..
S25S TDUNR-15 25 23 250 19,5 ≥39 DNM. 1506..
S25S TDUNL-15 25 23 250 19,5 ≥39 DNM. 1506..
S32T TDUNR-15 32 30 300 24 ≥40 DNM. 1506..
S32T TDUNL-15 32 30 300 24 ≥40 DNM. 1506..
S40U TDUNR-15 40 37 350 30 ≥50 DNM. 1506..
S40U TDUNL-15 40 37 350 30 ≥50 DNM. 1506..

Precise profiling for internal machining

The Internal Tool Holder - TDUNR/L (93°) with clamping by SMOXH is designed for the professional machining of internal contours. It is particularly suitable for roughing operations and offers a secure hold of the indexable inserts due to the proven claw clamping system.

Advantages of Internal Tool Holder - TDUNR/L (93°) with clamping

  • Particularly suitable for roughing due to stable claw clamping
  • Designed with a 93° cutting angle for flexible profiling operations
  • Robust construction supports reliable machining performance
Internal Tool Holder PSKNR/L (75°) SN.. 1204 | Rinaldi-Tools
Rinaldi-Tools GmbH

Internal Tool Holder - PSKNR/L (75°)

Price ab €63.00
Availability: 214748364 In Stock

Technical data

Boring Bar PSKNR/L
Cutting Angle 75°
Insert SN.. 1204
Main application Longitudinal turning
Clamping Pin Lock
Cooling Without Cooling Hole
Packaging unit 1 Pc.

Dimensions

d L h f Dmin
S25Q-PSKNR/L 12 25 180 23 17 32
S25T-PSKNR/L 12 25 300 23 17 32
S32R-PSKNR/L 12 32 200 30 22 44
S32U-PSKNR/L 12 32 350 30 22 44
S40S-PSKNR/L 12 40 250 37 27 54
S40V-PSKNR/L 12 40 400 37 27 54

Internal Tool Holder PSKNR/L for Professional Machining

The PSKNR/L internal tool holder featuring a 75° cutting angle is designed for efficient longitudinal turning and internal operations. Compatible with SN.. 1204 inserts, this holder is an excellent choice for turning applications that operate without internal coolant supply.

Advantages of Internal Tool Holder - PSKNR/L (75°)

  • Reliable pin lock clamping for secure fixation of SN.. 1204 inserts
  • Practical 75° cutting angle supports demanding inner contours
  • Available in various shank diameters ranging from 25 mm to 40 mm
  • Provided in multiple tool lengths up to 400 mm for deep boring
